DVALI S weighbridge series
60 Ton DVALI S Truck Scale
High-accuracy truck scale for daily commercial vehicle weighing in demanding environments. Built for reliability, high uptime, and long service life, the DVALI S range can be configured according to project requirements, requested features, and automation needs.
5-year warranty, pit or pitless installation, and flexible system configuration for different operating requirements.
- Designed for demanding environments
- High accuracy
- High reliability
- High uptime
- Long service life
- Flexible system configuration
- Automation-ready project direction
- 5-year warranty
Overview
Built for reliable daily truck weighing
The 60 Ton DVALI S Truck Scale is developed for businesses that need accurate and dependable commercial vehicle weighing in demanding operating conditions. It is positioned as a serious truck scale solution for everyday use, with strong emphasis on reliability, uptime, and long-term value.
The DVALI S range combines practical installation flexibility, durable truck scale architecture, and project-based system selection. This makes it suitable for buyers who need a serious truck scale platform rather than a one-format-only solution.
System configuration
Load cells, indicators, and automation paths
Load cell, indicator, and automation selection can be configured according to project requirements, requested features, site conditions, and workflow needs.
- CS, SC or CSD load cell directions
- ECI, ECI Digital, PWI-X, PWI-D or PWI-T indicator directions
- Automation-related solutions according to project scope
- Pit or pitless installation according to site conditions
Continue to load cell pages, weighing indicator pages, or service and support pages for the next decision layer.
Model matrix
Available 60 ton models
The 60 ton DVALI S range is available with 3 m platform width and platform lengths from 14 m to 24 m. Use the model matrix below to compare model codes, dimensions, and datasheets.
| Capacity | Model name | Model code | Minimum capacity | Division | Platform dimensions | Platform | Product datasheet |
|---|---|---|---|---|---|---|---|
| 60T | DVALI S Truck Scale 60 Ton - 3 × 14 m | 060T-Dvali-S-0314 | 400 kg | 20 kg | 3 × 14 m | Steel | Download 3 × 14 m datasheet |
| 60T | DVALI S Truck Scale 60 Ton - 3 × 16 m | 060T-Dvali-S-0316 | 400 kg | 20 kg | 3 × 16 m | Steel | Download 3 × 16 m datasheet |
| 60T | DVALI S Truck Scale 60 Ton - 3 × 18 m | 060T-Dvali-S-0318 | 400 kg | 20 kg | 3 × 18 m | Steel | Download 3 × 18 m datasheet |
| 60T | DVALI S Truck Scale 60 Ton - 3 × 20 m | 060T-Dvali-S-0320 | 400 kg | 20 kg | 3 × 20 m | Steel | Download 3 × 20 m datasheet |
| 60T | DVALI S Truck Scale 60 Ton - 3 × 22 m | 060T-Dvali-S-0322 | 400 kg | 20 kg | 3 × 22 m | Steel | Download 3 × 22 m datasheet |
| 60T | DVALI S Truck Scale 60 Ton - 3 × 24 m | 060T-Dvali-S-0324 | 400 kg | 20 kg | 3 × 24 m | Steel | Download 3 × 24 m datasheet |
Technical specifications
Core project and system data
Main technical and configuration data for the 60 Ton DVALI S Truck Scale.
Model class
- Nominal capacity
- 60T
- Minimum capacity
- 400 kg
- Division
- 20 kg
- Platform width
- 3 m
- Platform length options
- 14 m to 24 m
- Platform
- Steel
Load cell directions
- Available directions
- CS / SC / CSD
- Selection basis
- Project requirements and requested features
- Related pages
- Browse load cell pages
Indicator directions
- Available directions
- ECI / ECI Digital / PWI-X / PWI-D / PWI-T
- Selection basis
- Functions, workflow needs, and order requirements
- Related pages
- Browse indicator pages
Installation and support
- Installation type
- Pit or pitless
- Automation path
- Available according to project scope
- Warranty
- 5 years
- Support path
- Open service pages
Standard equipment
Standard scope
- Rubber feet
- Multi-load cell structure
- Low profile
- Steel cable enclosures
- Lightning protection
- Automatically increasing sequence number for each weighing ticket
- Memory capacity for 100,000 weighing records
- Fixed tare weight vehicle identification
- 10 configurable ticket information fields
- Detailed and sequential reporting by date range
- Customizable ticket and report formats
- Access to stored information according to selected criteria
- Printer connectivity
- Label and report printing
- Legal metrology approved
- CE certified
Options
Available project options
Configuration can be expanded with automation, control, traffic, and monitoring-related options depending on project requirements.
Continue to load cells, weighing indicators, and services for related project paths.
Gallery
60 Ton DVALI S truck scale visuals
Product and project images of the 60 ton DVALI S range.
FAQ
Frequently asked questions
Is the 60 Ton DVALI S Truck Scale suitable for demanding environments?
Yes. The 60 Ton DVALI S Truck Scale is positioned for accurate daily commercial vehicle weighing in demanding environments, with reliability, high uptime, and long service life as core priorities.
Which platform lengths are available for the 60 ton model?
Available platform dimensions are 3 × 14 m, 3 × 16 m, 3 × 18 m, 3 × 20 m, 3 × 22 m, and 3 × 24 m.
Is pit or pitless installation available?
Yes. The 60 Ton DVALI S Truck Scale can be supplied for pit or pitless installation according to site conditions.
Which load cells and indicators can be configured?
Depending on project requirements and requested features, DVALI can configure this model with CS, SC or CSD load cells and ECI, ECI Digital, PWI-X, PWI-D or PWI-T indicators.
Are automation-related solutions available?
Yes. Automation-related solutions can be integrated according to project requirements and workflow needs.
What warranty is offered for this model?
The 60 Ton DVALI S Truck Scale is backed by a 5-year warranty.
Request a quote
Request your 60 ton truck scale configuration
Send your required platform length, installation type, requested features, and automation needs. DVALI will help you select the right 60 ton configuration for your operation.
